Forklift Differential

Forklift Differential - A mechanical tool which can transmit torque and rotation through three shafts is referred to as a differential. At times but not at all times the differential would use gears and will function in two ways: in automobiles, it receives one input and provides two outputs. The other way a differential operates is to combine two inputs to generate an output that is the average, difference or sum of the inputs. In wheeled vehicles, the differential enables each of the tires to rotate at different speeds while supplying equal torque to each of them.

The differential is designed to drive a set of wheels with equivalent torque while allowing them to rotate at different speeds. While driving round corners, an automobile's wheels rotate at various speeds. Some vehicles such as karts operate without using a differential and utilize an axle as a substitute. If these vehicles are turning corners, both driving wheels are forced to spin at the same speed, usually on a common axle that is powered by a simple chain-drive mechanism. The inner wheel has to travel a shorter distance as opposed to the outer wheel while cornering. Without utilizing a differential, the result is the outer wheel dragging and or the inner wheel spinning. This puts strain on drive train, resulting in unpredictable handling, difficult driving and deterioration to the roads and tires.

The amount of traction considered necessary to be able to move the vehicle at whatever given moment depends on the load at that moment. How much friction or drag there is, the car's momentum, the gradient of the road and how heavy the car is are all contributing elements. One of the less desirable side effects of a conventional differential is that it can reduce grip under less than perfect conditions.

The end result of torque being provided to each wheel comes from the drive axles, transmission and engine applying force against the resistance of that grip on a wheel. Commonly, the drive train would provide as much torque as required except if the load is extremely high. The limiting element is commonly the traction under each wheel. Traction could be defined as the amount of torque that could be produced between the road exterior and the tire, before the wheel begins to slip. The car would be propelled in the intended direction if the torque used to the drive wheels does not exceed the threshold of traction. If the torque used to every wheel does exceed the traction limit then the wheels will spin continuously.
